John Deere
John Deere 6068HFG05
6068 Series
The John Deere 6068HFG05 is a 6.8-litre inline-6 diesel engine for generator sets, rated at 175 kVA / 140 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in United States. It meets U.S. EPA Final Tier 4 emissions standards.
- Standby Power · 50 Hz
- 175 kVA
- Electrical Output
- 140 kWe
- Cylinders
- L6
- Displacement
- 6.8 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 141.1 | 127 | 158.8 |
| Standby Power | 155.6 | 140 | 175 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 140 | 126 | 157.5 |
| Standby Power | 154.4 | 139 | 173.8 |
Technical Specifications
| Brand | John Deere |
| Model | 6068HFG05 |
| Series | 6068 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 6.8 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Final Tier 4 |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the John Deere 6068HFG05?
The John Deere 6068HFG05 is rated at 175 kVA standby / 159 kVA prime at 50 Hz (1,500 rpm); and 174 kVA standby / 158 kVA prime at 60 Hz (1,800 rpm).
Does the 6068HFG05 run at 50 Hz or 60 Hz?
The John Deere 6068HFG05 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the John Deere 6068HFG05 use?
The John Deere 6068HFG05 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 6068HFG05?
The John Deere 6068HFG05 is an inline-6 (6-cylinder) engine with a displacement of 6.8 L.
What emissions standard does the 6068HFG05 meet?
The John Deere 6068HFG05 is certified to U.S. EPA Final Tier 4 emissions standards.
Is the John Deere 6068HFG05 still in production?
Yes — the John Deere 6068HFG05 is a current production model.
Is a datasheet available for the 6068HFG05?
Yes — an official John Deere datasheet for the John Deere 6068HFG05 can be downloaded from this page.
