John Deere
John Deere 6136CG550
6136 Series
The John Deere 6136CG550 is a 13.6-litre inline-6 diesel engine for generator sets, rated at 564 kVA / 451 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in United States. It meets Euro Stage V / U.S. EPA Final Tier 4 emissions standards.
- Standby Power · 50 Hz
- 564 kVA
- Electrical Output
- 451 kWe
- Cylinders
- L6
- Displacement
- 13.6 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 451.1 | 406 | 507.5 |
| Standby Power | 501.1 | 451 | 563.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 444.4 | 400 | 500 |
| Standby Power | 493.3 | 444 | 555 |
Technical Specifications
| Brand | John Deere |
| Model | 6136CG550 |
| Series | 6136 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 13.6 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V / U.S. EPA Final Tier 4 |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the John Deere 6136CG550?
The John Deere 6136CG550 is rated at 564 kVA standby / 508 kVA prime at 50 Hz (1,500 rpm); and 555 kVA standby / 500 kVA prime at 60 Hz (1,800 rpm).
Does the 6136CG550 run at 50 Hz or 60 Hz?
The John Deere 6136CG550 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the John Deere 6136CG550 use?
The John Deere 6136CG550 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 6136CG550?
The John Deere 6136CG550 is an inline-6 (6-cylinder) engine with a displacement of 13.6 L.
What emissions standard does the 6136CG550 meet?
The John Deere 6136CG550 is certified to Euro Stage V / U.S. EPA Final Tier 4 emissions standards.
Is the John Deere 6136CG550 still in production?
Yes — the John Deere 6136CG550 is a current production model.
Is a datasheet available for the 6136CG550?
Yes — an official John Deere datasheet for the John Deere 6136CG550 can be downloaded from this page.
Related Engines
Compare John Deere 6136CG550
Reference
- Canonical page
- /engines/john-deere-6136cg550-ft4sv-500kva
- Last database update
- 2026-05-29
- Manufacturer files
- 1 datasheet linked
