Mitsubishi
Mitsubishi S6R2-PTAA-C
S6R Series
The Mitsubishi S6R2-PTAA-C is a 17.46-litre inline-6 diesel engine for generator sets, rated at 799 kVA / 639 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 799 kVA
- Electrical Output
- 639 kWe
- Cylinders
- L6
- Displacement
- 17.46 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 645 | 580.5 | 725.6 |
| Standby Power | 710 | 639 | 798.8 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Technical Specifications
| Brand | Mitsubishi |
| Model | S6R2-PTAA-C |
| Series | S6R Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 17.46 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Mitsubishi S6R2-PTAA-C?
The Mitsubishi S6R2-PTAA-C is rated at 799 kVA standby / 726 kVA prime at 50 Hz (1,500 rpm).
Does the S6R2-PTAA-C run at 50 Hz or 60 Hz?
The Mitsubishi S6R2-PTAA-C is rated for 50 Hz (1,500 rpm).
What fuel does the Mitsubishi S6R2-PTAA-C use?
The Mitsubishi S6R2-PTAA-C is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S6R2-PTAA-C?
The Mitsubishi S6R2-PTAA-C is an inline-6 (6-cylinder) engine with a displacement of 17.46 L.
Is the Mitsubishi S6R2-PTAA-C still in production?
Yes — the Mitsubishi S6R2-PTAA-C is a current production model.
Is a datasheet available for the S6R2-PTAA-C?
Yes — an official Mitsubishi datasheet for the Mitsubishi S6R2-PTAA-C can be downloaded from this page.
