MTU
MTU MTU 16V2000 G45
2000 Series
MTU 16V2000 G45 is a 31.856 L V16 turbocharged and intercooled diesel engine. EPA annual certification data lists TB and TD 3B/3D constant-speed configurations from 915 to 1010 kWm at 1800 RPM under Tier 2.
Get help with this engine
Tell Haifeng whether you already own a MTU MTU 16V2000 G45 engine/generator or need to source this model for a project.
- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-25
- Package route
- diesel generator sets
- Standby Power · 60 Hz
- 1,136 kVA
- Electrical Output
- 909 kWe
- Cylinders
- V16
- Displacement
- 31.856 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 1010 | 909 | 1136.3 |
MTU MTU 16V2000 G45 generator set context
The MTU MTU 16V2000 G45 is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 1,136 kVA / 909 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | MTU |
| Model | MTU 16V2000 G45 |
| Series | 2000 Series |
| Configuration | V16 Turbocharged Intercooled |
| Cylinders | 16 |
| Displacement | 31.856 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Certifications | U.S. EPA Tier 2 |
| Country of Origin | Germany |
Frequently asked questions
What is the power output of the MTU MTU 16V2000 G45?
The MTU MTU 16V2000 G45 is rated at 1,136 kVA standby at 60 Hz (1,800 rpm).
Does the MTU 16V2000 G45 run at 50 Hz or 60 Hz?
The MTU MTU 16V2000 G45 is rated for 60 Hz (1,800 rpm).
What fuel does the MTU MTU 16V2000 G45 use?
The MTU MTU 16V2000 G45 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the MTU 16V2000 G45?
The MTU MTU 16V2000 G45 is a V16 (16-cylinder) engine with a displacement of 31.856 L.
What emissions standard does the MTU 16V2000 G45 meet?
The MTU MTU 16V2000 G45 is certified to U.S. EPA Tier 2 emissions standards.
Is the MTU MTU 16V2000 G45 still in production?
Yes — the MTU MTU 16V2000 G45 is a current production model.
Is a datasheet available for the MTU 16V2000 G45?
Yes — an official MTU datasheet for the MTU MTU 16V2000 G45 can be downloaded from this page.
