MTU
MTU MTU 16V2000 G85
2000 Series
MTU 16V2000 G85 is a 31.856 L V16 turbocharged and intercooled diesel engine. EPA annual certification data lists TB and TD 3B/3D constant-speed configurations from 1010 to 1115 kWm at 1800 RPM under Tier 2.
Get help with this engine
Tell Haifeng whether you already own a MTU MTU 16V2000 G85 engine/generator or need to source this model for a project.
- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-25
- Package route
- diesel generator sets
- Standby Power · 60 Hz
- 1,255 kVA
- Electrical Output
- 1,004 kWe
- Cylinders
- V16
- Displacement
- 31.856 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 1115.6 | 1004 | 1255 |
MTU MTU 16V2000 G85 generator set context
The MTU MTU 16V2000 G85 is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 1,255 kVA / 1,004 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | MTU |
| Model | MTU 16V2000 G85 |
| Series | 2000 Series |
| Configuration | V16 Turbocharged Intercooled |
| Cylinders | 16 |
| Displacement | 31.856 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Certifications | U.S. EPA Tier 2 |
| Country of Origin | Germany |
Frequently asked questions
What is the power output of the MTU MTU 16V2000 G85?
The MTU MTU 16V2000 G85 is rated at 1,255 kVA standby at 60 Hz (1,800 rpm).
Does the MTU 16V2000 G85 run at 50 Hz or 60 Hz?
The MTU MTU 16V2000 G85 is rated for 60 Hz (1,800 rpm).
What fuel does the MTU MTU 16V2000 G85 use?
The MTU MTU 16V2000 G85 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the MTU 16V2000 G85?
The MTU MTU 16V2000 G85 is a V16 (16-cylinder) engine with a displacement of 31.856 L.
What emissions standard does the MTU 16V2000 G85 meet?
The MTU MTU 16V2000 G85 is certified to U.S. EPA Tier 2 emissions standards.
Is the MTU MTU 16V2000 G85 still in production?
Yes — the MTU MTU 16V2000 G85 is a current production model.
Is a datasheet available for the MTU 16V2000 G85?
Yes — an official MTU datasheet for the MTU MTU 16V2000 G85 can be downloaded from this page.
