MTU

MTU MTU 16V4000 G23

4000 Series

In Production

The MTU MTU 16V4000 G23 is a 76.3-litre V16 diesel engine for generator sets, rated at 2,225 kVA / 1,780 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in Germany.

Get help with this engine

Tell Haifeng whether you already own a MTU MTU 16V4000 G23 engine/generator or need to source this model for a project.

I need service / overhaul supportFor overhaul, parts, documents, troubleshooting, or replacement matching.For clients who already have this engine or generator: overhaul, spare parts, documentation, troubleshooting, or replacement matching.WhatsApp service request I need to source this engineFor projects, tenders, overseas sourcing, availability, or equivalents.For projects, client leads, tenders, overseas sourcing, package availability, or acceptable equivalents.WhatsApp sourcing request

Download datasheet Compare engine Get a quote

Manufacturer files: 1 datasheet
Last updated: 2026-05-29
Package route: diesel generator sets

Standby Power · 50 Hz: 2,225 kVA
Electrical Output: 1,780 kWe
Cylinders: V16
Displacement: 76.3 L
Rated Speed: 1,500 RPM

Power Ratings

kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf

50 Hz1500 RPM

	kWm	kWe	kVA
Prime Power	1797.8	1618	2022.5
Standby Power	1977.8	1780	2225

MTU MTU 16V4000 G23 76.3L V16 diesel generator engine — 2,225 kVA standby specifications — Shareable spec cardMTU MTU 16V4000 G23 summary imageOpen image

MTU MTU 16V4000 G23 generator set context

The MTU MTU 16V4000 G23 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 2,225 kVA / 1,780 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.

Also searched as

mtu16v4000g23MTU MTU 16V4000 G234000 Series MTU 16V4000 G23

BrandAll MTU engines CompareSimilar engines Haifeng packagediesel generator sets

Technical Specifications

Brand	MTU
Model	MTU 16V4000 G23
Series	4000 Series
Configuration	V16
Cylinders	16
Displacement	76.3 L
Fuel Type	Diesel
Ignition Type	Compression Ignition
Cooling Method	Liquid-Cooled
Emissions Standard	Unregulated
Country of Origin	Germany

Frequently asked questions

What is the power output of the MTU MTU 16V4000 G23?

The MTU MTU 16V4000 G23 is rated at 2,225 kVA standby / 2,023 kVA prime at 50 Hz (1,500 rpm).

Does the MTU 16V4000 G23 run at 50 Hz or 60 Hz?

The MTU MTU 16V4000 G23 is rated for 50 Hz (1,500 rpm).

What fuel does the MTU MTU 16V4000 G23 use?

The MTU MTU 16V4000 G23 is a diesel generator-set engine.

What is the displacement and cylinder configuration of the MTU 16V4000 G23?

The MTU MTU 16V4000 G23 is a V16 (16-cylinder) engine with a displacement of 76.3 L.

Is the MTU MTU 16V4000 G23 still in production?

Yes — the MTU MTU 16V4000 G23 is a current production model.

Is a datasheet available for the MTU 16V4000 G23?

Yes — an official MTU datasheet for the MTU MTU 16V4000 G23 can be downloaded from this page.
