MTU
MTU MTU 20V4000 G14F
4000 Series
The MTU MTU 20V4000 G14F is a 95.4-litre V20 diesel engine for generator sets, rated at 2,723 kVA / 2,178 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in Germany.
- Standby Power · 50 Hz
- 2,723 kVA
- Electrical Output
- 2,178 kWe
- Cylinders
- V20
- Displacement
- 95.4 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2200 | 1980 | 2475 |
| Standby Power | 2420 | 2178 | 2722.5 |
Technical Specifications
| Brand | MTU |
| Model | MTU 20V4000 G14F |
| Series | 4000 Series |
| Configuration | V20 |
| Cylinders | 20 |
| Displacement | 95.4 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Germany |
Frequently asked questions
What is the power output of the MTU MTU 20V4000 G14F?
The MTU MTU 20V4000 G14F is rated at 2,723 kVA standby / 2,475 kVA prime at 50 Hz (1,500 rpm).
Does the MTU 20V4000 G14F run at 50 Hz or 60 Hz?
The MTU MTU 20V4000 G14F is rated for 50 Hz (1,500 rpm).
What fuel does the MTU MTU 20V4000 G14F use?
The MTU MTU 20V4000 G14F is a diesel generator-set engine.
What is the displacement and cylinder configuration of the MTU 20V4000 G14F?
The MTU MTU 20V4000 G14F is a V20 (20-cylinder) engine with a displacement of 95.4 L.
Is the MTU MTU 20V4000 G14F still in production?
Yes — the MTU MTU 20V4000 G14F is a current production model.
Is a datasheet available for the MTU 20V4000 G14F?
Yes — an official MTU datasheet for the MTU MTU 20V4000 G14F can be downloaded from this page.
Related Engines
Compare MTU MTU 20V4000 G14F
Reference
- Canonical page
- /engines/mtu-20v4000-g14f
- Last database update
- 2026-05-29
- Manufacturer files
- 1 datasheet linked
