MTU

MTU MTU 20V4000 G63LF

4000 Series

In Production

The MTU MTU 20V4000 G63LF is a 95.4-litre V20 diesel engine for generator sets, rated at 3,205 kVA / 2,564 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in Germany.

Get help with this engine

Tell Haifeng whether you already own a MTU MTU 20V4000 G63LF engine/generator or need to source this model for a project.

I need service / overhaul supportFor overhaul, parts, documents, troubleshooting, or replacement matching.For clients who already have this engine or generator: overhaul, spare parts, documentation, troubleshooting, or replacement matching.WhatsApp service request I need to source this engineFor projects, tenders, overseas sourcing, availability, or equivalents.For projects, client leads, tenders, overseas sourcing, package availability, or acceptable equivalents.WhatsApp sourcing request

Download datasheet Compare engine Get a quote

Manufacturer files: 1 datasheet
Last updated: 2026-05-29
Package route: diesel generator sets

Standby Power · 50 Hz: 3,205 kVA
Electrical Output: 2,564 kWe
Cylinders: V20
Displacement: 95.4 L
Rated Speed: 1,500 RPM

Power Ratings

kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf

50 Hz1500 RPM

	kWm	kWe	kVA
Prime Power	2590	2331	2913.8
Standby Power	2848.9	2564	3205

MTU MTU 20V4000 G63LF 95.4L V20 diesel generator engine — 3,205 kVA standby specifications — Shareable spec cardMTU MTU 20V4000 G63LF summary imageOpen image

MTU MTU 20V4000 G63LF generator set context

The MTU MTU 20V4000 G63LF is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 3,205 kVA / 2,564 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.

Also searched as

mtu20v4000g63lfMTU MTU 20V4000 G63LF4000 Series MTU 20V4000 G63LF

BrandAll MTU engines CompareSimilar engines Haifeng packagediesel generator sets

Technical Specifications

Brand	MTU
Model	MTU 20V4000 G63LF
Series	4000 Series
Configuration	V20
Cylinders	20
Displacement	95.4 L
Fuel Type	Diesel
Ignition Type	Compression Ignition
Cooling Method	Liquid-Cooled
Emissions Standard	Unregulated
Country of Origin	Germany

Frequently asked questions

What is the power output of the MTU MTU 20V4000 G63LF?

The MTU MTU 20V4000 G63LF is rated at 3,205 kVA standby / 2,914 kVA prime at 50 Hz (1,500 rpm).

Does the MTU 20V4000 G63LF run at 50 Hz or 60 Hz?

The MTU MTU 20V4000 G63LF is rated for 50 Hz (1,500 rpm).

What fuel does the MTU MTU 20V4000 G63LF use?

The MTU MTU 20V4000 G63LF is a diesel generator-set engine.

What is the displacement and cylinder configuration of the MTU 20V4000 G63LF?

The MTU MTU 20V4000 G63LF is a V20 (20-cylinder) engine with a displacement of 95.4 L.

Is the MTU MTU 20V4000 G63LF still in production?

Yes — the MTU MTU 20V4000 G63LF is a current production model.

Is a datasheet available for the MTU 20V4000 G63LF?

Yes — an official MTU datasheet for the MTU MTU 20V4000 G63LF can be downloaded from this page.
