MTU
MTU MTU 20V4000 G83L
4000 Series
MTU 20V4000 G83L is a 95.332 L V20 diesel engine. EPA records list 3B, 3D and 3F configurations from 3010 to 3490 kWm at 1800 RPM under Tier 2.
Get help with this engine
Tell Haifeng whether you already own a MTU MTU 20V4000 G83L engine/generator or need to source this model for a project.
- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-25
- Package route
- diesel generator sets
- Standby Power · 60 Hz
- 3,725 kVA
- Electrical Output
- 2,980 kWe
- Cylinders
- V20
- Displacement
- 95.332 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 3010 | 2709 | 3386.3 |
| Standby Power | 3311.1 | 2980 | 3725 |
MTU MTU 20V4000 G83L generator set context
The MTU MTU 20V4000 G83L is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 3,725 kVA / 2,980 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | MTU |
| Model | MTU 20V4000 G83L |
| Series | 4000 Series |
| Configuration | V20 Turbocharged Intercooled |
| Cylinders | 20 |
| Displacement | 95.332 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Certifications | U.S. EPA Tier 2 |
| Country of Origin | Germany |
Frequently asked questions
What is the power output of the MTU MTU 20V4000 G83L?
The MTU MTU 20V4000 G83L is rated at 3,725 kVA standby / 3,386 kVA prime at 60 Hz (1,800 rpm).
Does the MTU 20V4000 G83L run at 50 Hz or 60 Hz?
The MTU MTU 20V4000 G83L is rated for 60 Hz (1,800 rpm).
What fuel does the MTU MTU 20V4000 G83L use?
The MTU MTU 20V4000 G83L is a diesel generator-set engine.
What is the displacement and cylinder configuration of the MTU 20V4000 G83L?
The MTU MTU 20V4000 G83L is a V20 (20-cylinder) engine with a displacement of 95.332 L.
What emissions standard does the MTU 20V4000 G83L meet?
The MTU MTU 20V4000 G83L is certified to U.S. EPA Tier 2 emissions standards.
Is the MTU MTU 20V4000 G83L still in production?
Yes — the MTU MTU 20V4000 G83L is a current production model.
Is a datasheet available for the MTU 20V4000 G83L?
Yes — an official MTU datasheet for the MTU MTU 20V4000 G83L can be downloaded from this page.
