SDEC
SDEC 12KTA58-G32
K Series
The SDEC 12KTA58-G32 is a 58-litre V12 diesel engine for generator sets, rated at 2,290 kVA / 1,832 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Get help with this engine
Tell Haifeng whether you already own a SDEC 12KTA58-G32 engine/generator or need to source this model for a project.
- Manufacturer files
- No datasheet
- Last updated
- 2026-07-24
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 2,290 kVA
- Electrical Output
- 1,832 kWe
- Cylinders
- V12
- Displacement
- 58 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1850 | 1665 | 2081.3 |
| Standby Power | 2035 | 1832 | 2290 |
SDEC 12KTA58-G32 generator set context
The SDEC 12KTA58-G32 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 2,290 kVA / 1,832 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | SDEC |
| Model | 12KTA58-G32 |
| Series | K Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 58 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the SDEC 12KTA58-G32?
The SDEC 12KTA58-G32 is rated at 2,290 kVA standby / 2,081 kVA prime at 50 Hz (1,500 rpm).
Does the 12KTA58-G32 run at 50 Hz or 60 Hz?
The SDEC 12KTA58-G32 is rated for 50 Hz (1,500 rpm).
What fuel does the SDEC 12KTA58-G32 use?
The SDEC 12KTA58-G32 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 12KTA58-G32?
The SDEC 12KTA58-G32 is a V12 (12-cylinder) engine with a displacement of 58 L.
Is the SDEC 12KTA58-G32 still in production?
Yes — the SDEC 12KTA58-G32 is a current production model.
