SDEC

SDEC 16XTAA38-G34

X Series

In Production

The SDEC 16XTAA38-G34 is a 38-litre V16 diesel engine for generator sets, rated at 1,260 kVA / 1,008 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.

Get help with this engine

Tell Haifeng whether you already own a SDEC 16XTAA38-G34 engine/generator or need to source this model for a project.

I need service / overhaul supportFor overhaul, parts, documents, troubleshooting, or replacement matching.For clients who already have this engine or generator: overhaul, spare parts, documentation, troubleshooting, or replacement matching.WhatsApp service request I need to source this engineFor projects, tenders, overseas sourcing, availability, or equivalents.For projects, client leads, tenders, overseas sourcing, package availability, or acceptable equivalents.WhatsApp sourcing request

Request datasheet Compare engine Get a quote

Manufacturer files: No datasheet
Last updated: 2026-07-24
Package route: diesel generator sets

Standby Power · 50 Hz: 1,260 kVA
Electrical Output: 1,008 kWe
Cylinders: V16
Displacement: 38 L
Rated Speed: 1,500 RPM

Power Ratings

kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf

50 Hz1500 RPM

	kWm	kWe	kVA
Prime Power	1018	916	1145
Standby Power	1120	1008	1260

SDEC 16XTAA38-G34 38L V16 diesel generator engine — 1,260 kVA standby specifications — Shareable spec cardSDEC 16XTAA38-G34 summary imageOpen image

SDEC 16XTAA38-G34 generator set context

The SDEC 16XTAA38-G34 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 1,260 kVA / 1,008 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.

Also searched as

16xtaa38g3416XTAA38 G34SDEC 16XTAA38-G34X Series 16XTAA38-G34

BrandAll SDEC engines CompareSimilar engines Haifeng packagediesel generator sets

Technical Specifications

Brand	SDEC
Model	16XTAA38-G34
Series	X Series
Configuration	V16
Cylinders	16
Displacement	38 L
Fuel Type	Diesel
Ignition Type	Compression Ignition
Cooling Method	Liquid-Cooled
Emissions Standard	China National Stage III / Unregulated
Country of Origin	China

Frequently asked questions

What is the power output of the SDEC 16XTAA38-G34?

The SDEC 16XTAA38-G34 is rated at 1,260 kVA standby / 1,145 kVA prime at 50 Hz (1,500 rpm).

Does the 16XTAA38-G34 run at 50 Hz or 60 Hz?

The SDEC 16XTAA38-G34 is rated for 50 Hz (1,500 rpm).

What fuel does the SDEC 16XTAA38-G34 use?

The SDEC 16XTAA38-G34 is a diesel generator-set engine.

What is the displacement and cylinder configuration of the 16XTAA38-G34?

The SDEC 16XTAA38-G34 is a V16 (16-cylinder) engine with a displacement of 38 L.
