SDEC
SDEC 4Z2.3-G21
Z Series
The SDEC 4Z2.3-G21 is a 2.3-litre inline-4 diesel engine for generator sets, rated at 20 kVA / 16 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 20 kVA
- Electrical Output
- 16 kWe
- Cylinders
- L4
- Displacement
- 2.3 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 15.6 | 14 | 17.5 |
| Standby Power | 17.8 | 16 | 20 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 21.1 | 19 | 23.8 |
| Standby Power | 23.3 | 21 | 26.3 |
Technical Specifications
| Brand | SDEC |
| Model | 4Z2.3-G21 |
| Series | Z Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 2.3 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage II / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the SDEC 4Z2.3-G21?
The SDEC 4Z2.3-G21 is rated at 20 kVA standby / 18 kVA prime at 50 Hz (1,500 rpm); and 26 kVA standby / 24 kVA prime at 60 Hz (1,800 rpm).
Does the 4Z2.3-G21 run at 50 Hz or 60 Hz?
The SDEC 4Z2.3-G21 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the SDEC 4Z2.3-G21 use?
The SDEC 4Z2.3-G21 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4Z2.3-G21?
The SDEC 4Z2.3-G21 is an inline-4 (4-cylinder) engine with a displacement of 2.3 L.
Is the SDEC 4Z2.3-G21 still in production?
Yes — the SDEC 4Z2.3-G21 is a current production model.
Is a datasheet available for the 4Z2.3-G21?
Yes — an official SDEC datasheet for the SDEC 4Z2.3-G21 can be downloaded from this page.
