SDEC
SDEC 4ZTAA3.5-G31
Z Series
The SDEC 4ZTAA3.5-G31 is a 3.5-litre inline-4 diesel engine for generator sets, rated at 91 kVA / 73 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Get help with this engine
Tell Haifeng whether you already own a SDEC 4ZTAA3.5-G31 engine/generator or need to source this model for a project.
- Manufacturer files
- 2 datasheets
- Last updated
- 2026-07-24
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 91 kVA
- Electrical Output
- 73 kWe
- Cylinders
- L4
- Displacement
- 3.5 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 74 | 67 | 83.8 |
| Standby Power | 81 | 73 | 91.3 |
SDEC 4ZTAA3.5-G31 generator set context
The SDEC 4ZTAA3.5-G31 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 91 kVA / 73 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | SDEC |
| Model | 4ZTAA3.5-G31 |
| Series | Z Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 3.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the SDEC 4ZTAA3.5-G31?
The SDEC 4ZTAA3.5-G31 is rated at 91 kVA standby / 84 kVA prime at 50 Hz (1,500 rpm).
Does the 4ZTAA3.5-G31 run at 50 Hz or 60 Hz?
The SDEC 4ZTAA3.5-G31 is rated for 50 Hz (1,500 rpm).
What fuel does the SDEC 4ZTAA3.5-G31 use?
The SDEC 4ZTAA3.5-G31 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4ZTAA3.5-G31?
The SDEC 4ZTAA3.5-G31 is an inline-4 (4-cylinder) engine with a displacement of 3.5 L.
Is the SDEC 4ZTAA3.5-G31 still in production?
Yes — the SDEC 4ZTAA3.5-G31 is a current production model.
Is a datasheet available for the 4ZTAA3.5-G31?
Yes — an official SDEC datasheet for the SDEC 4ZTAA3.5-G31 can be downloaded from this page.
