Weichai
Weichai 12M26D968E200
M26 Series
The Weichai 12M26D968E200 is a 31.2-litre V12 diesel engine for generator sets, rated at 1,089 kVA / 871 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Get help with this engine
Tell Haifeng whether you already own a Weichai 12M26D968E200 engine/generator or need to source this model for a project.
- Manufacturer files
- 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,089 kVA
- Electrical Output
- 871 kWe
- Cylinders
- V12
- Displacement
- 31.2 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 880 | 792 | 990 |
| Standby Power | 967.8 | 871 | 1088.8 |
Weichai 12M26D968E200 generator set context
The Weichai 12M26D968E200 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 1,089 kVA / 871 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Weichai |
| Model | 12M26D968E200 |
| Series | M26 Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 31.2 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage II / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Weichai 12M26D968E200?
The Weichai 12M26D968E200 is rated at 1,089 kVA standby / 990 kVA prime at 50 Hz (1,500 rpm).
Does the 12M26D968E200 run at 50 Hz or 60 Hz?
The Weichai 12M26D968E200 is rated for 50 Hz (1,500 rpm).
What fuel does the Weichai 12M26D968E200 use?
The Weichai 12M26D968E200 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 12M26D968E200?
The Weichai 12M26D968E200 is a V12 (12-cylinder) engine with a displacement of 31.2 L.
Is the Weichai 12M26D968E200 still in production?
Yes — the Weichai 12M26D968E200 is a current production model.
Is a datasheet available for the 12M26D968E200?
Yes — an official Weichai datasheet for the Weichai 12M26D968E200 can be downloaded from this page.
