Weichai
Weichai 16M33D1280NG10
M33 Series
The Weichai 16M33D1280NG10 is a 52.8-litre V16 natural gas engine for generator sets, rated at 1,375 kVA / 1,100 kWe prime power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Prime Power · 50 Hz
- 1,375 kVA
- Electrical Output
- 1,100 kWe
- Cylinders
- V16
- Displacement
- 52.8 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1280 | 1100 | 1375 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1280 | 1152 | 1440 |
Technical Specifications
| Brand | Weichai |
| Model | 16M33D1280NG10 |
| Series | M33 Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 52.8 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Weichai 16M33D1280NG10?
The Weichai 16M33D1280NG10 is rated at 1,375 kVA prime at 50 Hz (1,500 rpm); and 1,440 kVA prime at 60 Hz (1,800 rpm).
Does the 16M33D1280NG10 run at 50 Hz or 60 Hz?
The Weichai 16M33D1280NG10 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Weichai 16M33D1280NG10 use?
The Weichai 16M33D1280NG10 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the 16M33D1280NG10?
The Weichai 16M33D1280NG10 is a V16 (16-cylinder) engine with a displacement of 52.8 L.
Is the Weichai 16M33D1280NG10 still in production?
Yes — the Weichai 16M33D1280NG10 is a current production model.
Is a datasheet available for the 16M33D1280NG10?
Yes — an official Weichai datasheet for the Weichai 16M33D1280NG10 can be downloaded from this page.
