Yuchai
Yuchai YCD6Q23H8-210
V75
The Yuchai YCD6Q23H8-210 is a 7.42-litre inline-6 diesel engine for generator sets, rated at 163 kVA / 130 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Get help with this engine
Tell Haifeng whether you already own a Yuchai YCD6Q23H8-210 engine/generator or need to source this model for a project.
- Manufacturer files
- No datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 163 kVA
- Electrical Output
- 130 kWe
- Cylinders
- L6
- Displacement
- 7.42 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 133.3 | 120 | 150 |
| Standby Power | 144.4 | 130 | 162.5 |
Yuchai YCD6Q23H8-210 generator set context
The Yuchai YCD6Q23H8-210 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 163 kVA / 130 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Yuchai |
| Model | YCD6Q23H8-210 |
| Series | V75 |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7.42 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Yuchai YCD6Q23H8-210?
The Yuchai YCD6Q23H8-210 is rated at 163 kVA standby / 150 kVA prime at 50 Hz (1,500 rpm).
Does the YCD6Q23H8-210 run at 50 Hz or 60 Hz?
The Yuchai YCD6Q23H8-210 is rated for 50 Hz (1,500 rpm).
What fuel does the Yuchai YCD6Q23H8-210 use?
The Yuchai YCD6Q23H8-210 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the YCD6Q23H8-210?
The Yuchai YCD6Q23H8-210 is an inline-6 (6-cylinder) engine with a displacement of 7.42 L.
Is the Yuchai YCD6Q23H8-210 still in production?
Yes — the Yuchai YCD6Q23H8-210 is a current production model.
