ABC
ABC 16VDZ
VDZC
ABC 16VDZ is an Anglo Belgian Corporation medium-speed 16VDZ genset product data page power-generation engine. The ABC product page validates a V16 configuration, up to 3,395 kWe at 50 Hz and up to 3,057 kWe at 60 Hz, with diesel, gas oil, HFO, biofuel and vegetable oil operation. Fuel injection: Direct, mechanical, one pump per cylinder. These ratings are listed for generator-set applications.
Overhaul & repair parts- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-08-25
- Package route
- diesel generator sets
- Prime Power · 50 Hz
- 4,244 kVA
- Electrical Output
- 3,395 kWe
- Cylinders
- V16
- Displacement
- 255.3 L
- Rated Speed
- 1,000 / 1,200 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 3395 | 3395 | 4243.8 |
60 Hz1200 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 3057 | 3057 | 3821.3 |
Ask about ABC 16VDZ
Choose parts / service or sourcing. Your message includes this model and page link.
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamABC 16VDZ overhaul & repair parts
Already running a ABC 16VDZ? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 16VDZ and your selected categories included. Attach your photos there.
ABC 16VDZ generator set context
The ABC 16VDZ is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 4,244 kVA / 3,395 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | ABC |
| Model | 16VDZ |
| Series | VDZC |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 255.3 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Application-dependent |
| Country of Origin | Belgium |
Frequently asked questions
What is the power output of the ABC 16VDZ?
The ABC 16VDZ is rated at 4,244 kVA prime at 50 Hz (1,000 rpm); and 3,821 kVA prime at 60 Hz (1,200 rpm).
Does the 16VDZ run at 50 Hz or 60 Hz?
The ABC 16VDZ is available for both 50 Hz (1,000 rpm) and 60 Hz (1,200 rpm).
What fuel does the ABC 16VDZ use?
The ABC 16VDZ is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 16VDZ?
The ABC 16VDZ is a V16 (16-cylinder) engine with a displacement of 255.3 L.
What emissions information is listed for the 16VDZ?
This record lists Application-dependent for the ABC 16VDZ. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the ABC 16VDZ?
The ABC 16VDZ is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 16VDZ?
This page links reference documents for the ABC 16VDZ. Check each document's title, model coverage, revision and rating conditions before using it for selection.
