ABC
ABC 8DL36
DL36
ABC 8DL36 is an Anglo Belgian Corporation medium-speed 8DL36 genset product data page power-generation engine. The ABC product page validates a L8 configuration, up to 5,063 kWe at 50 Hz and up to 4,860 kWe at 60 Hz, with diesel, gas oil and HFO operation. Fuel injection: Direct, mechanical, one pump per cylinder; common rail alternative. These ratings are listed for generator-set applications.
Overhaul & repair parts- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-08-25
- Package route
- diesel generator sets
- Prime Power · 50 Hz
- 6,329 kVA
- Electrical Output
- 5,063 kWe
- Cylinders
- L8
- Displacement
- 351.6 L
- Rated Speed
- 750 / 900 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz750 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 5063 | 5063 | 6328.8 |
60 Hz900 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 4860 | 4860 | 6075 |
Ask about ABC 8DL36
Choose parts / service or sourcing. Your message includes this model and page link.
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamABC 8DL36 overhaul & repair parts
Already running a ABC 8DL36? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 8DL36 and your selected categories included. Attach your photos there.
ABC 8DL36 generator set context
The ABC 8DL36 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 6,329 kVA / 5,063 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | ABC |
| Model | 8DL36 |
| Series | DL36 |
| Configuration | L8 |
| Cylinders | 8 |
| Displacement | 351.6 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Application-dependent |
| Country of Origin | Belgium |
Frequently asked questions
What is the power output of the ABC 8DL36?
The ABC 8DL36 is rated at 6,329 kVA prime at 50 Hz (750 rpm); and 6,075 kVA prime at 60 Hz (900 rpm).
Does the 8DL36 run at 50 Hz or 60 Hz?
The ABC 8DL36 is available for both 50 Hz (750 rpm) and 60 Hz (900 rpm).
What fuel does the ABC 8DL36 use?
The ABC 8DL36 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 8DL36?
The ABC 8DL36 is an inline-8 (8-cylinder) engine with a displacement of 351.6 L.
What emissions information is listed for the 8DL36?
This record lists Application-dependent for the ABC 8DL36. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the ABC 8DL36?
The ABC 8DL36 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 8DL36?
This page links reference documents for the ABC 8DL36. Check each document's title, model coverage, revision and rating conditions before using it for selection.
