ABC
ABC 8DZ DF
DZD Dual Fuel
ABC 8DZ DF is an Anglo Belgian Corporation medium-speed 8DZ DF genset product data page power-generation engine. The ABC product page validates a L8 configuration, up to 1,268 kWe at 50 Hz and up to 1,140 kWe at 60 Hz, with CNG, LNG, waste gas or landfill gas with diesel pilot capability. Fuel injection: Direct fuel injection. These ratings are listed for generator-set applications.
Get help with this engine
Tell Haifeng whether you already own a ABC 8DZ DF engine/generator or need to source this model for a project.
- Manufacturer files
- 1 datasheet
- Last updated
- 2026-08-25
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 1,585 kVA
- Electrical Output
- 1,268 kWe
- Cylinders
- L8
- Displacement
- 127.7 L
- Rated Speed
- 1,000 / 1,200 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1268 | 1268 | 1585 |
60 Hz1200 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1140 | 1140 | 1425 |
ABC 8DZ DF generator set context
The ABC 8DZ DF is listed here as a natural gas generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,585 kVA / 1,268 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | ABC |
| Model | 8DZ DF |
| Series | DZD Dual Fuel |
| Configuration | L8 |
| Cylinders | 8 |
| Displacement | 127.7 L |
| Fuel Type | Natural Gas |
| Ignition Type | Pilot Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Application-dependent |
| Country of Origin | Belgium |
Frequently asked questions
What is the power output of the ABC 8DZ DF?
The ABC 8DZ DF is rated at 1,585 kVA prime at 50 Hz (1,000 rpm); and 1,425 kVA prime at 60 Hz (1,200 rpm).
Does the 8DZ DF run at 50 Hz or 60 Hz?
The ABC 8DZ DF is available for both 50 Hz (1,000 rpm) and 60 Hz (1,200 rpm).
What fuel does the ABC 8DZ DF use?
The ABC 8DZ DF is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the 8DZ DF?
The ABC 8DZ DF is an inline-8 (8-cylinder) engine with a displacement of 127.7 L.
What emissions standard does the 8DZ DF meet?
The ABC 8DZ DF is certified to Application-dependent emissions standards.
Is the ABC 8DZ DF still in production?
Yes — the ABC 8DZ DF is a current production model.
Is a datasheet available for the 8DZ DF?
Yes — an official ABC datasheet for the ABC 8DZ DF can be downloaded from this page.
