ABC
ABC 8DZ DF MeOH
DZD MeOH
ABC 8DZ DF MeOH is an Anglo Belgian Corporation medium-speed 8DZ DF MeOH genset product data page power-generation engine. The ABC product page validates a L8 configuration, up to 1,680 kWe at 50 Hz and up to 1,512 kWe at 60 Hz, with up to 70% methanol with 30% (bio)diesel/HVO, or 100% (bio)diesel/HVO. Fuel injection: Direct injection for (bio)diesel/HVO and port injection for methanol. These ratings are listed for generator-set applications.
Overhaul & repair parts- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-08-25
- Package route
- diesel generator sets
- Prime Power · 50 Hz
- 2,100 kVA
- Electrical Output
- 1,680 kWe
- Cylinders
- L8
- Displacement
- 127.7 L
- Rated Speed
- 1,000 / 1,200 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1680 | 1680 | 2100 |
60 Hz1200 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1512 | 1512 | 1890 |
Ask about ABC 8DZ DF MeOH
Choose parts / service or sourcing. Your message includes this model and page link.
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamABC 8DZ DF MeOH overhaul & repair parts
Already running a ABC 8DZ DF MeOH? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 8DZ DF MeOH and your selected categories included. Attach your photos there.
ABC 8DZ DF MeOH generator set context
The ABC 8DZ DF MeOH is listed here as a methanol generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 2,100 kVA / 1,680 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | ABC |
| Model | 8DZ DF MeOH |
| Series | DZD MeOH |
| Configuration | L8 |
| Cylinders | 8 |
| Displacement | 127.7 L |
| Fuel Type | Methanol |
| Ignition Type | Pilot Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Application-dependent |
| Country of Origin | Belgium |
Frequently asked questions
What is the power output of the ABC 8DZ DF MeOH?
The ABC 8DZ DF MeOH is rated at 2,100 kVA prime at 50 Hz (1,000 rpm); and 1,890 kVA prime at 60 Hz (1,200 rpm).
Does the 8DZ DF MeOH run at 50 Hz or 60 Hz?
The ABC 8DZ DF MeOH is available for both 50 Hz (1,000 rpm) and 60 Hz (1,200 rpm).
What fuel does the ABC 8DZ DF MeOH use?
The ABC 8DZ DF MeOH is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 8DZ DF MeOH?
The ABC 8DZ DF MeOH is an inline-8 (8-cylinder) engine with a displacement of 127.7 L.
What emissions information is listed for the 8DZ DF MeOH?
This record lists Application-dependent for the ABC 8DZ DF MeOH. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the ABC 8DZ DF MeOH?
The ABC 8DZ DF MeOH is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 8DZ DF MeOH?
This page links reference documents for the ABC 8DZ DF MeOH. Check each document's title, model coverage, revision and rating conditions before using it for selection.
