Arrow
Arrow A54E
Arrow Gaseous Engines
Arrow A54E is a 5.4 L inline-6 naturally aspirated, spark-ignited gaseous engine. Arrow lists 48 kWm prime and 53 kWm standby natural-gas ratings at 1800 RPM, with EPA stationary, nonroad mobile and emergency-standby certification. EPA annual data contains a 62.5 kW maximum certification node for this family.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-25
- Package route
- gas generator sets
- Standby Power · 60 Hz
- 60 kVA
- Electrical Output
- 48 kWe
- Cylinders
- L6
- Displacement
- 5.4 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 48 | 43 | 53.75 |
| Standby Power | 53 | 48 | 60 |
Ask about Arrow A54E
Choose parts / service or sourcing. Your message includes this model and page link.
Arrow A54E overhaul & repair parts
Already running a Arrow A54E? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with A54E and your selected categories included. Attach your photos there.
Arrow A54E generator set context
The Arrow A54E is listed here as a natural gas generator-drive engine for 60 Hz generator sets, with a headline 60 kVA / 48 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Arrow |
| Model | A54E |
| Series | Arrow Gaseous Engines |
| Configuration | L6 Naturally Aspirated |
| Cylinders | 6 |
| Displacement | 5.4 L |
| Compression Ratio | 8:1 |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Stationary |
| Certifications | U.S. EPA Stationary, U.S. EPA Nonroad Mobile, U.S. EPA Emergency Standby |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the Arrow A54E?
The Arrow A54E is rated at 60 kVA standby / 54 kVA prime at 60 Hz (1,800 rpm).
Does the A54E run at 50 Hz or 60 Hz?
The Arrow A54E is rated for 60 Hz (1,800 rpm).
What fuel does the Arrow A54E use?
The Arrow A54E is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the A54E?
The Arrow A54E is an inline-6 (6-cylinder) engine with a displacement of 5.4 L.
What emissions information is listed for the A54E?
This record lists U.S. EPA Stationary for the Arrow A54E. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Arrow A54E?
The Arrow A54E is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the A54E?
This page links reference documents for the Arrow A54E. Check each document's title, model coverage, revision and rating conditions before using it for selection.
