Baudouin
Baudouin 12M26G1000/5
12M26 Series
The Baudouin 12M26G1000/5 is a 31.2-litre V12 diesel engine for generator sets, rated at 1,000 kVA / 800 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in France.
Get help with this engine
Tell Haifeng whether you already own a Baudouin 12M26G1000/5 engine/generator or need to source this model for a project.
- Manufacturer files
- 1 datasheet
- Last updated
- 2026-06-07
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,000 kVA
- Electrical Output
- 800 kWe
- Cylinders
- V12
- Displacement
- 31.2 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 820 | 720 | 900 |
| Standby Power | 902 | 800 | 1000 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1014 | 910 | 1138 |
| Standby Power | 1115 | 1000 | 1250 |
Baudouin 12M26G1000/5 generator set context
The Baudouin 12M26G1000/5 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,000 kVA / 800 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Baudouin |
| Model | 12M26G1000/5 |
| Series | 12M26 Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 31.2 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | France |
Frequently asked questions
What is the power output of the Baudouin 12M26G1000/5?
The Baudouin 12M26G1000/5 is rated at 1,000 kVA standby / 900 kVA prime at 50 Hz (1,500 rpm); and 1,250 kVA standby / 1,138 kVA prime at 60 Hz (1,800 rpm).
Does the 12M26G1000/5 run at 50 Hz or 60 Hz?
The Baudouin 12M26G1000/5 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Baudouin 12M26G1000/5 use?
The Baudouin 12M26G1000/5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 12M26G1000/5?
The Baudouin 12M26G1000/5 is a V12 (12-cylinder) engine with a displacement of 31.2 L.
Is the Baudouin 12M26G1000/5 still in production?
Yes — the Baudouin 12M26G1000/5 is a current production model.
Is a datasheet available for the 12M26G1000/5?
Yes — an official Baudouin datasheet for the Baudouin 12M26G1000/5 can be downloaded from this page.
