Baudouin
Baudouin 16M33G2250/5^
16M33 Series
The Baudouin 16M33G2250/5^ is a 52.8-litre V16 diesel engine for generator sets, rated at 2,250 kVA / 1,800 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in France.
- Standby Power · 50 Hz
- 2,250 kVA
- Electrical Output
- 1,800 kWe
- Cylinders
- V16
- Displacement
- 52.8 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1800 | 1600 | 2000 |
| Standby Power | 1980 | 1800 | 2250 |
Technical Specifications
| Brand | Baudouin |
| Model | 16M33G2250/5^ |
| Series | 16M33 Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 52.8 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | France |
Frequently asked questions
What is the power output of the Baudouin 16M33G2250/5^?
The Baudouin 16M33G2250/5^ is rated at 2,250 kVA standby / 2,000 kVA prime at 50 Hz (1,500 rpm).
Does the 16M33G2250/5^ run at 50 Hz or 60 Hz?
The Baudouin 16M33G2250/5^ is rated for 50 Hz (1,500 rpm).
What fuel does the Baudouin 16M33G2250/5^ use?
The Baudouin 16M33G2250/5^ is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 16M33G2250/5^?
The Baudouin 16M33G2250/5^ is a V16 (16-cylinder) engine with a displacement of 52.8 L.
Is the Baudouin 16M33G2250/5^ still in production?
Yes — the Baudouin 16M33G2250/5^ is a current production model.
Is a datasheet available for the 16M33G2250/5^?
Yes — an official Baudouin datasheet for the Baudouin 16M33G2250/5^ can be downloaded from this page.
Related Engines
Compare Baudouin 16M33G2250/5^
Reference
- Canonical page
- /engines/baudouin-16m33g2250-5
- Last database update
- 2026-06-07
- Manufacturer files
- 1 datasheet linked
