Baudouin
Baudouin 4M06G44/5
4M06 Series
The Baudouin 4M06G44/5 is a 2.4-litre inline-4 diesel engine for generator sets, rated at 44 kVA / 35 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in France.
- Standby Power · 50 Hz
- 44 kVA
- Electrical Output
- 35 kWe
- Cylinders
- L4
- Displacement
- 2.4 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 37 | 32 | 40 |
| Standby Power | 41 | 35 | 44 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 38.9 | 35 | 43.8 |
| Standby Power | 42.8 | 39 | 48.8 |
Technical Specifications
| Brand | Baudouin |
| Model | 4M06G44/5 |
| Series | 4M06 Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 2.4 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | France |
Frequently asked questions
What is the power output of the Baudouin 4M06G44/5?
The Baudouin 4M06G44/5 is rated at 44 kVA standby / 40 kVA prime at 50 Hz (1,500 rpm); and 49 kVA standby / 44 kVA prime at 60 Hz (1,800 rpm).
Does the 4M06G44/5 run at 50 Hz or 60 Hz?
The Baudouin 4M06G44/5 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Baudouin 4M06G44/5 use?
The Baudouin 4M06G44/5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4M06G44/5?
The Baudouin 4M06G44/5 is an inline-4 (4-cylinder) engine with a displacement of 2.4 L.
Is the Baudouin 4M06G44/5 still in production?
Yes — the Baudouin 4M06G44/5 is a current production model.
Is a datasheet available for the 4M06G44/5?
Yes — an official Baudouin datasheet for the Baudouin 4M06G44/5 can be downloaded from this page.
