Baudouin
Baudouin 6M33G715/5
6M33 Series
The Baudouin 6M33G715/5 is a 19.8-litre inline-6 diesel engine for generator sets, rated at 715 kVA / 572 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in France.
- Standby Power · 50 Hz
- 715 kVA
- Electrical Output
- 572 kWe
- Cylinders
- L6
- Displacement
- 19.8 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 575 | 520 | 650 |
| Standby Power | 633 | 572 | 715 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 635.6 | 572 | 715 |
| Standby Power | 702.5 | 632 | 790 |
Technical Specifications
| Brand | Baudouin |
| Model | 6M33G715/5 |
| Series | 6M33 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 19.8 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | France |
Frequently asked questions
What is the power output of the Baudouin 6M33G715/5?
The Baudouin 6M33G715/5 is rated at 715 kVA standby / 650 kVA prime at 50 Hz (1,500 rpm); and 790 kVA standby / 715 kVA prime at 60 Hz (1,800 rpm).
Does the 6M33G715/5 run at 50 Hz or 60 Hz?
The Baudouin 6M33G715/5 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Baudouin 6M33G715/5 use?
The Baudouin 6M33G715/5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 6M33G715/5?
The Baudouin 6M33G715/5 is an inline-6 (6-cylinder) engine with a displacement of 19.8 L.
Is the Baudouin 6M33G715/5 still in production?
Yes — the Baudouin 6M33G715/5 is a current production model.
Is a datasheet available for the 6M33G715/5?
Yes — an official Baudouin datasheet for the Baudouin 6M33G715/5 can be downloaded from this page.
Related Engines
Compare Baudouin 6M33G715/5
Reference
- Canonical page
- /engines/baudouin-6m33g715-5
- Last database update
- 2026-06-07
- Manufacturer files
- 2 datasheets linked
