Bergen
Bergen B36:45V12
B36:45
Bergen B36:45V12 — 549.7 L V12 (360 × 450 mm) lean-burn spark-ignited natural-gas engine generating set (Bergen B36:45 series), 600 kW/cylinder. 7090 kWe at 750 rpm / 50 Hz; for power plants.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-08
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 8,863 kVA
- Electrical Output
- 7,090 kWe
- Cylinders
- V12
- Displacement
- 549.7 L
- Rated Speed
- 750 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz750 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 7090 | 8862.5 |
Ask about Bergen B36:45V12
Choose parts / service or sourcing. Your message includes this model and page link.
Bergen B36:45V12 overhaul & repair parts
Already running a Bergen B36:45V12? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with B36:45V12 and your selected categories included. Attach your photos there.
Bergen B36:45V12 generator set context
The Bergen B36:45V12 is listed here as a natural gas generator-drive engine for 50 Hz generator sets, with a headline 8,863 kVA / 7,090 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Bergen |
| Model | B36:45V12 |
| Series | B36:45 |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 549.7 L |
| Dry Weight | 100000 kg |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Norway |
Frequently asked questions
What is the power output of the Bergen B36:45V12?
The Bergen B36:45V12 is rated at 8,863 kVA prime at 50 Hz (750 rpm).
Does the B36:45V12 run at 50 Hz or 60 Hz?
The Bergen B36:45V12 is rated for 50 Hz (750 rpm).
What fuel does the Bergen B36:45V12 use?
The Bergen B36:45V12 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the B36:45V12?
The Bergen B36:45V12 is a V12 (12-cylinder) engine with a displacement of 549.7 L.
What is the catalog status of the Bergen B36:45V12?
The Bergen B36:45V12 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the B36:45V12?
This page links reference documents for the Bergen B36:45V12. Check each document's title, model coverage, revision and rating conditions before using it for selection.
