Caterpillar
Caterpillar 3516B 50 Hz 1750-2250 kVA Legacy Genset
3516B
Caterpillar 3516B 50 Hz 1750-2250 kVA Legacy Genset discontinued/non-current diesel generator-set package. Cat H-CPC marks the source page as Non-Current and links the official LEHE1281-00 Cat spec sheet validating the 2250 kVA / 1800 ekW standby and 1750 kVA / 1400 ekW continuous rating.
Chat on WhatsApp about this engine
Opens WhatsApp with Caterpillar 3516B 50 Hz 1750-2250 kVA Legacy Genset and this page link filled in.
- Manufacturer files
- 1 datasheet
- Last updated
- 2026-08-12
- Package route
- diesel generator sets
- Electrical Output
- 1,800 kW
- Cylinders
- V16
- Displacement
- 69 L
- Rated Speed
- 1,500 RPM
Caterpillar 3516B 50 Hz 1750-2250 kVA Legacy Genset generator set context
The Caterpillar 3516B 50 Hz 1750-2250 kVA Legacy Genset is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 1,800 kW / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Caterpillar |
| Model | 3516B 50 Hz 1750-2250 kVA Legacy Genset |
| Series | 3516B |
| Configuration | 3516B V-16 four-stroke water-cooled diesel generator-set engine |
| Cylinders | 16 |
| Displacement | 69 L |
| Compression Ratio | 14.0:1 |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Low Fuel Consumption or Low Emissions |
| Certifications | Caterpillar Non-Current product page, Official Caterpillar spec sheet |
| Country of Origin | United States |
Frequently asked questions
What fuel does the Caterpillar 3516B 50 Hz 1750-2250 kVA Legacy Genset use?
The Caterpillar 3516B 50 Hz 1750-2250 kVA Legacy Genset is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 3516B 50 Hz 1750-2250 kVA Legacy Genset?
The Caterpillar 3516B 50 Hz 1750-2250 kVA Legacy Genset is a V16 (16-cylinder) engine with a displacement of 69 L.
What emissions standard does the 3516B 50 Hz 1750-2250 kVA Legacy Genset meet?
The Caterpillar 3516B 50 Hz 1750-2250 kVA Legacy Genset is certified to Low Fuel Consumption or Low Emissions emissions standards.
Is the 3516B 50 Hz 1750-2250 kVA Legacy Genset still in production?
No — the Caterpillar 3516B 50 Hz 1750-2250 kVA Legacy Genset is discontinued. Its specifications and datasheets remain archived here for reference.
Is a datasheet available for the 3516B 50 Hz 1750-2250 kVA Legacy Genset?
Yes — an official Caterpillar datasheet for the Caterpillar 3516B 50 Hz 1750-2250 kVA Legacy Genset can be downloaded from this page.
