Caterpillar
Caterpillar 3516C 50 Hz 2500-3125 kVA Legacy Genset
3516C
Caterpillar 3516C 50 Hz 2500-3125 kVA Legacy Genset discontinued/non-current diesel generator-set package. Cat H-CPC marks the source page as Non-Current and links the official LEHE1343-13 Cat spec sheet validating the 3125 kVA / 2500 ekW standby and 2500 kVA / 2000 ekW package coverage rating.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-08-12
- Package route
- diesel generator sets
- Mechanical Output
- 2,500 kW
- Cylinders
- V16
- Displacement
- 78.08 L
- Rated Speed
- 1,500 RPM
Ask about Caterpillar 3516C 50 Hz 2500-3125 kVA Legacy Genset
Choose parts / service or sourcing. Your message includes this model and page link.
Caterpillar 3516C 50 Hz 2500-3125 kVA Legacy Genset overhaul & repair parts
Already running a Caterpillar 3516C 50 Hz 2500-3125 kVA Legacy Genset? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 3516C 50 Hz 2500-3125 kVA Legacy Genset and your selected categories included. Attach your photos there.
Caterpillar 3516C 50 Hz 2500-3125 kVA Legacy Genset generator set context
The Caterpillar 3516C 50 Hz 2500-3125 kVA Legacy Genset is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 2,500 kW / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Caterpillar |
| Model | 3516C 50 Hz 2500-3125 kVA Legacy Genset |
| Series | 3516C |
| Configuration | 3516C V-16 four-stroke water-cooled diesel generator-set engine |
| Cylinders | 16 |
| Displacement | 78.08 L |
| Compression Ratio | 15.5:1 |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Low Fuel Consumption or Low Emissions |
| Certifications | Caterpillar Non-Current product page, Official Caterpillar spec sheet |
| Country of Origin | United States |
Frequently asked questions
What fuel does the Caterpillar 3516C 50 Hz 2500-3125 kVA Legacy Genset use?
The Caterpillar 3516C 50 Hz 2500-3125 kVA Legacy Genset is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 3516C 50 Hz 2500-3125 kVA Legacy Genset?
The Caterpillar 3516C 50 Hz 2500-3125 kVA Legacy Genset is a V16 (16-cylinder) engine with a displacement of 78.08 L.
What emissions information is listed for the 3516C 50 Hz 2500-3125 kVA Legacy Genset?
This record lists Low Fuel Consumption or Low Emissions for the Caterpillar 3516C 50 Hz 2500-3125 kVA Legacy Genset. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
Is the 3516C 50 Hz 2500-3125 kVA Legacy Genset still in production?
No — the Caterpillar 3516C 50 Hz 2500-3125 kVA Legacy Genset is discontinued. Its specifications and datasheets remain archived here for reference.
Are reference documents available for the 3516C 50 Hz 2500-3125 kVA Legacy Genset?
This page links reference documents for the Caterpillar 3516C 50 Hz 2500-3125 kVA Legacy Genset. Check each document's title, model coverage, revision and rating conditions before using it for selection.
