Caterpillar
Caterpillar C13B
C-Series High-Speed Industrial
Caterpillar C13B 12.5 L inline-6 high-speed industrial diesel engine rated from 340 to 430 kW at 1800-2100 RPM. Cat documents DOC, DPF and SCR aftertreatment and EU Stage V / U.S. EPA Tier 4 Final compliance. EPA data confirms constant-speed 1800 RPM configurations; generator-package electrical output must be engineered separately.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-24
- Package route
- diesel generator sets
- Maximum Mechanical Power
- 430 kW
- Cylinders
- L6
- Displacement
- 12.5 L
- Rated Speed
- 1,800 RPM
Ask about Caterpillar C13B
Choose parts / service or sourcing. Your message includes this model and page link.
Caterpillar C13B overhaul & repair parts
Already running a Caterpillar C13B? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with C13B and your selected categories included. Attach your photos there.
Caterpillar C13B industrial power context
The Caterpillar C13B is a high-speed industrial diesel engine rated at 430 kW mechanical output at 1,800 RPM. It is used in off-road equipment and can support engineered variable-speed power systems, but its maximum power is not a direct 50/60 Hz alternator rating. Verify the drivetrain, power electronics, cooling, and emissions installation with Volvo Penta before specifying a generator package.
Also searched as
Technical Specifications
| Brand | Caterpillar |
| Model | C13B |
| Series | C-Series High-Speed Industrial |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 12.5 L |
| Compression Ratio | 15.8:1 |
| Dry Weight | 1125 kg |
| Dimensions (L×W×H) | 1274 × 994 × 1134 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V / U.S. EPA Final Tier 4 |
| Certifications | EU Stage V, U.S. EPA Tier 4 Final |
| Country of Origin | United States |
| Year Introduced | 2020 |
Frequently asked questions
What is the maximum power output of the Caterpillar C13B?
The Caterpillar C13B has a maximum mechanical output of 430 kW at 1,800 rpm. This is a variable-speed off-road rating, not a fixed-speed generator-set rating.
What fuel does the Caterpillar C13B use?
The Caterpillar C13B is a diesel variable-speed industrial engine.
What is the displacement and cylinder configuration of the C13B?
The Caterpillar C13B is an inline-6 (6-cylinder) engine with a displacement of 12.5 L.
What emissions information is listed for the C13B?
This record lists Euro Stage V / U.S. EPA Final Tier 4 for the Caterpillar C13B. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Caterpillar C13B?
The Caterpillar C13B is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the C13B?
This page links reference documents for the Caterpillar C13B. Check each document's title, model coverage, revision and rating conditions before using it for selection.
