Caterpillar C2.2
The Caterpillar C2.2 is a 2.2-litre in-line 4, turbocharged diesel engine for generator sets, rated at 22 kVA / 18 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in USA. It meets Euro Stage IIIA emissions standards.
- Standby Power · 50 Hz
- 22 kVA
- Electrical Output
- 18 kWe
- Cylinders
- In-line 4, Turbocharged
- Displacement
- 2.2 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 16 | 20 |
| Standby Power | — | 17.6 | 22 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 18 | 22.5 |
| Standby Power | — | 20 | 25 |
Technical Specifications
| Brand | Caterpillar |
| Model | C2.2 |
| Configuration | In-line 4, Turbocharged |
| Cylinders | 4 |
| Displacement | 2.2 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage IIIA |
| Country of Origin | USA |
