Caterpillar C3.3
The Caterpillar C3.3 is a 3.3-litre in-line 4, turbocharged diesel engine for generator sets, rated at 65 kVA / 52 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in USA.
- Standby Power · 50 Hz
- 65 kVA
- Electrical Output
- 52 kWe
- Cylinders
- In-line 4, Turbocharged
- Displacement
- 3.3 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 48 | 60 |
| Standby Power | — | 52 | 65 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 55 | 68.8 |
| Standby Power | — | 60 | 75 |
Technical Specifications
| Brand | Caterpillar |
| Model | C3.3 |
| Configuration | In-line 4, Turbocharged |
| Cylinders | 4 |
| Displacement | 3.3 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | USA |
