Caterpillar
Caterpillar CG132B-16
CG132
Caterpillar CG132B-16 — 35.1 L V16 spark-ignited natural gas generator engine (Cat CG132 series). 1000 ekW continuous at 1500 rpm (800 ekW @ 60 Hz); lean-burn, ≤250 mg/Nm³ NOx; multi-fuel (NG/biogas/propane). Source: Cat 2024 Electric Power Ratings Guide.
- Prime Power · 50 Hz
- 1,250 kVA
- Electrical Output
- 1,000 kWe
- Cylinders
- V16
- Displacement
- 35.1 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1000 | 1250 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 800 | 1000 |
Caterpillar CG132B-16 generator set context
The Caterpillar CG132B-16 is listed here as a natural gas generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,250 kVA / 1,000 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Caterpillar |
| Model | CG132B-16 |
| Series | CG132 |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 35.1 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Germany |
Frequently asked questions
What is the power output of the Caterpillar CG132B-16?
The Caterpillar CG132B-16 is rated at 1,250 kVA prime at 50 Hz (1,500 rpm); and 1,000 kVA prime at 60 Hz (1,800 rpm).
Does the CG132B-16 run at 50 Hz or 60 Hz?
The Caterpillar CG132B-16 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Caterpillar CG132B-16 use?
The Caterpillar CG132B-16 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the CG132B-16?
The Caterpillar CG132B-16 is a V16 (16-cylinder) engine with a displacement of 35.1 L.
Is the Caterpillar CG132B-16 still in production?
Yes — the Caterpillar CG132B-16 is a current production model.
Is a datasheet available for the CG132B-16?
Yes — an official Caterpillar datasheet for the Caterpillar CG132B-16 can be downloaded from this page.
