Caterpillar
Caterpillar CG170-16
CG170
Caterpillar CG170-16 — 70.8 L V16 spark-ignited natural gas generator engine (Cat CG170 series). 1560 ekW continuous at 1500 rpm; lean-burn, ≤250 mg/Nm³ NOx; multi-fuel (NG/biogas/propane). Source: Cat 2024 Electric Power Ratings Guide.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-06-11
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 1,950 kVA
- Electrical Output
- 1,560 kWe
- Cylinders
- V16
- Displacement
- 70.8 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1560 | 1950 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1560 | 1950 |
Ask about Caterpillar CG170-16
Choose parts / service or sourcing. Your message includes this model and page link.
Caterpillar CG170-16 overhaul & repair parts
Already running a Caterpillar CG170-16? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with CG170-16 and your selected categories included. Attach your photos there.
Caterpillar CG170-16 generator set context
The Caterpillar CG170-16 is listed here as a natural gas generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,950 kVA / 1,560 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Caterpillar |
| Model | CG170-16 |
| Series | CG170 |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 70.8 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Germany |
Frequently asked questions
What is the power output of the Caterpillar CG170-16?
The Caterpillar CG170-16 is rated at 1,950 kVA prime at 50 Hz (1,500 rpm); and 1,950 kVA prime at 60 Hz (1,800 rpm).
Does the CG170-16 run at 50 Hz or 60 Hz?
The Caterpillar CG170-16 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Caterpillar CG170-16 use?
The Caterpillar CG170-16 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the CG170-16?
The Caterpillar CG170-16 is a V16 (16-cylinder) engine with a displacement of 70.8 L.
What is the catalog status of the Caterpillar CG170-16?
The Caterpillar CG170-16 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the CG170-16?
This page links reference documents for the Caterpillar CG170-16. Check each document's title, model coverage, revision and rating conditions before using it for selection.
