Caterpillar CG18
Caterpillar CG18 is an 18.1 L inline-6 turbocharged and air-to-air aftercooled natural-gas engine for 60 Hz generator sets. The official Cat DG500 specification lists 500 kWe standby at 1800 RPM and EPA stationary emergency and non-emergency compliance; EPA annual certification data lists 567 kWm.
Production StatusIn Production
CG
- Configuration
- L6 Turbocharged Air-to-Air Aftercooled
- Displacement
- 18.1 L
- Fuel
- Natural Gas
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| Rating | Standby |
|---|---|
| Electrical output kWe | 500 |
| Apparent power kVA | 625 |
Datasheet & documents
Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.
Technical specifications
Technical Specifications
| Brand | Caterpillar |
| Model | CG18 |
| Series | CG |
| Configuration | L6 Turbocharged Air-to-Air Aftercooled |
| Cylinders | 6 |
| Displacement | 18.1 L |
| Compression Ratio | 10.5:1 |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Stationary |
| Certifications | U.S. EPA Stationary Emergency, U.S. EPA Stationary Non-Emergency |
| Country of Origin | United States |
Check your engine model
The Caterpillar CG18 is a natural gas generator-drive engine for 60 Hz generator sets, rated at 625 kVA / 500 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.
Other ways this model is written
cg18Caterpillar CG18
CG18 repair parts
Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.
Get a parts & air-shipping quoteIn-stock parts: same-day dispatch
Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.
Find the right part
Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.
Get my parts quote on WhatsAppWe’ll confirm the correct parts, stock and delivery cost before you order.
Opens WhatsApp. Attach photos in the chat.
Photos and details to send
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Parts reference availability
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Get help with this engine
Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.
Other ways to contact us
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamNeed help after checking the documents?
Send us the part number or describe the problem. This engine model is included in your message.
Send this model enquiry by emailOr browse Haifeng's gas generator sets
Frequently asked questions
What is the power output of the Caterpillar CG18?
The Caterpillar CG18 is rated at 625 kVA standby at 60 Hz (1,800 rpm).
Does the CG18 run at 50 Hz or 60 Hz?
The Caterpillar CG18 is rated for 60 Hz (1,800 rpm).
What fuel does the Caterpillar CG18 use?
The Caterpillar CG18 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the CG18?
The Caterpillar CG18 is an inline-6 (6-cylinder) engine with a displacement of 18.1 L.
What emissions information is listed for the CG18?
This record lists U.S. EPA Stationary for the Caterpillar CG18. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Caterpillar CG18?
The Caterpillar CG18 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the CG18?
This page links reference documents for the Caterpillar CG18. Check each document's title, model coverage, revision and rating conditions before using it for selection.
