Caterpillar CG260-16
Caterpillar CG260-16 — 272 L V16 spark-ignited natural gas generator engine (Cat CG260 series). 4500 ekW continuous at 1000 rpm (4050 ekW @ 60 Hz); high-efficiency lean-burn, ≤250 mg/Nm³ NOx; ~45% electrical efficiency. Source: Cat 2024 Electric Power Ratings Guide.
Production StatusIn Production
CG260
- Configuration
- V16
- Displacement
- 272 L
- Fuel
- Natural Gas
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| Rating | Prime |
|---|---|
| Electrical output kWe | 4,500 |
| Apparent power kVA | 5,625 |
60 Hz1200 RPM
| Rating | Prime |
|---|---|
| Electrical output kWe | 4,050 |
| Apparent power kVA | 5,062.5 |
Datasheet & documents
Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.
Technical specifications
Technical Specifications
| Brand | Caterpillar |
| Model | CG260-16 |
| Series | CG260 |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 272 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Germany |
Check your engine model
The Caterpillar CG260-16 is a natural gas generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 5,625 kVA / 4,500 kWe / prime rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.
Other ways this model is written
cg26016CG260 16Caterpillar CG260-16
CG260-16 repair parts
Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.
Get a parts & air-shipping quoteIn-stock parts: same-day dispatch
Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.
Find the right part
Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.
Other parts? Add them in the chat.
Get my parts quote on WhatsAppWe’ll confirm the correct parts, stock and delivery cost before you order.
Opens WhatsApp. Attach photos in the chat.
Photos and details to send
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
These categories have model-related records. Part numbers need further checking before we display them here.
Get help with this engine
Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.
Other ways to contact us
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamNeed help after checking the documents?
Send us the part number or describe the problem. This engine model is included in your message.
Send this model enquiry by emailOr browse Haifeng's gas generator sets
Frequently asked questions
What is the power output of the Caterpillar CG260-16?
The Caterpillar CG260-16 is rated at 5,625 kVA prime at 50 Hz (1,000 rpm); and 5,063 kVA prime at 60 Hz (1,200 rpm).
Does the CG260-16 run at 50 Hz or 60 Hz?
The Caterpillar CG260-16 is available for both 50 Hz (1,000 rpm) and 60 Hz (1,200 rpm).
What fuel does the Caterpillar CG260-16 use?
The Caterpillar CG260-16 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the CG260-16?
The Caterpillar CG260-16 is a V16 (16-cylinder) engine with a displacement of 272 L.
What is the catalog status of the Caterpillar CG260-16?
The Caterpillar CG260-16 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the CG260-16?
This page links reference documents for the Caterpillar CG260-16. Check each document's title, model coverage, revision and rating conditions before using it for selection.
