Caterpillar
Caterpillar G3516+
3500
Caterpillar G3516+ — 67.4 L V16 spark-ignited biogas generator engine (Cat G3500 series). 1000 ekW continuous at 1200 rpm; biogas variant (1000 ekW @ 1200 rpm). Source: Cat 2024 Electric Power Ratings Guide.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-06-11
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 1,250 kVA
- Electrical Output
- 1,000 kWe
- Cylinders
- V16
- Displacement
- 67.4 L
- Rated Speed
- 1,200 / 1,440 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1200 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1000 | 1250 |
60 Hz1440 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1000 | 1250 |
Ask about Caterpillar G3516+
Choose parts / service or sourcing. Your message includes this model and page link.
Caterpillar G3516+ overhaul & repair parts
Already running a Caterpillar G3516+? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with G3516+ and your selected categories included. Attach your photos there.
Caterpillar G3516+ generator set context
The Caterpillar G3516+ is listed here as a biogas generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,250 kVA / 1,000 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Caterpillar |
| Model | G3516+ |
| Series | 3500 |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 67.4 L |
| Fuel Type | Biogas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Stationary |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the Caterpillar G3516+?
The Caterpillar G3516+ is rated at 1,250 kVA prime at 50 Hz (1,200 rpm); and 1,250 kVA prime at 60 Hz (1,440 rpm).
Does the G3516+ run at 50 Hz or 60 Hz?
The Caterpillar G3516+ is available for both 50 Hz (1,200 rpm) and 60 Hz (1,440 rpm).
What fuel does the Caterpillar G3516+ use?
The Caterpillar G3516+ is a Biogas generator-set engine.
What is the displacement and cylinder configuration of the G3516+?
The Caterpillar G3516+ is a V16 (16-cylinder) engine with a displacement of 67.4 L.
What emissions information is listed for the G3516+?
This record lists U.S. EPA Stationary for the Caterpillar G3516+. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Caterpillar G3516+?
The Caterpillar G3516+ is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the G3516+?
This page links reference documents for the Caterpillar G3516+. Check each document's title, model coverage, revision and rating conditions before using it for selection.
