Cummins
Cummins 4BTA3.9-G11
B3.9 Series
The Cummins 4BTA3.9-G11 is a 3.9-litre inline-4 diesel engine for generator sets, rated at 100 kVA / 80 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Overhaul & repair parts- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 100 kVA
- Electrical Output
- 80 kWe
- Cylinders
- L4
- Displacement
- 3.9 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 71.1 | 64 | 80 |
| Standby Power | 88.9 | 80 | 100 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 80 | 72 | 90 |
| Standby Power | 100 | 90 | 112.5 |
Ask about Cummins 4BTA3.9-G11
Choose parts / service or sourcing. Your message includes this model and page link.
Cummins 4BTA3.9-G11 overhaul & repair parts
Already running a Cummins 4BTA3.9-G11? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 4BTA3.9-G11 and your selected categories included. Attach your photos there.
Cummins 4BTA3.9-G11 generator set context
The Cummins 4BTA3.9-G11 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 100 kVA / 80 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Cummins |
| Model | 4BTA3.9-G11 |
| Series | B3.9 Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 3.9 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Cummins 4BTA3.9-G11?
The Cummins 4BTA3.9-G11 is rated at 100 kVA standby / 80 kVA prime at 50 Hz (1,500 rpm); and 113 kVA standby / 90 kVA prime at 60 Hz (1,800 rpm).
Does the 4BTA3.9-G11 run at 50 Hz or 60 Hz?
The Cummins 4BTA3.9-G11 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Cummins 4BTA3.9-G11 use?
The Cummins 4BTA3.9-G11 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4BTA3.9-G11?
The Cummins 4BTA3.9-G11 is an inline-4 (4-cylinder) engine with a displacement of 3.9 L.
What is the catalog status of the Cummins 4BTA3.9-G11?
The Cummins 4BTA3.9-G11 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 4BTA3.9-G11?
This page links reference documents for the Cummins 4BTA3.9-G11. Check each document's title, model coverage, revision and rating conditions before using it for selection.
