Cummins
Cummins 6ZTAA13-G4
Z13 Series
The Cummins 6ZTAA13-G4 is a 13-litre inline-6 diesel engine for generator sets, rated at 548 kVA / 438 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 548 kVA
- Electrical Output
- 438 kWe
- Cylinders
- L6
- Displacement
- 13 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 388.9 | 350 | 437.5 |
| Standby Power | 486.7 | 438 | 547.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 388.9 | 350 | 437.5 |
| Standby Power | 486.7 | 438 | 547.5 |
Technical Specifications
| Brand | Cummins |
| Model | 6ZTAA13-G4 |
| Series | Z13 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 13 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Cummins 6ZTAA13-G4?
The Cummins 6ZTAA13-G4 is rated at 548 kVA standby / 438 kVA prime at 50 Hz (1,500 rpm); and 548 kVA standby / 438 kVA prime at 60 Hz (1,800 rpm).
Does the 6ZTAA13-G4 run at 50 Hz or 60 Hz?
The Cummins 6ZTAA13-G4 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Cummins 6ZTAA13-G4 use?
The Cummins 6ZTAA13-G4 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 6ZTAA13-G4?
The Cummins 6ZTAA13-G4 is an inline-6 (6-cylinder) engine with a displacement of 13 L.
Is the Cummins 6ZTAA13-G4 still in production?
Yes — the Cummins 6ZTAA13-G4 is a current production model.
Is a datasheet available for the 6ZTAA13-G4?
Yes — an official Cummins datasheet for the Cummins 6ZTAA13-G4 can be downloaded from this page.
