Cummins
Cummins C1600N6CD
HSK78G Genset
Cummins C1600N6CD is a 1600 kWe continuous-duty, 60 Hz natural-gas generator set using the HSK78G engine at 1800 RPM. The official 2025 North American range card does not publish an EPA certification for this model, so no emissions claim is assigned.
- Prime Power · 60 Hz
- 2,000 kVA
- Electrical Output
- 1,600 kWe
- Cylinders
- V12
- Displacement
- 78 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1600 | 2000 |
Cummins C1600N6CD generator set context
The Cummins C1600N6CD is listed here as a natural gas generator-drive engine for 60 Hz generator sets, with a headline 2,000 kVA / 1,600 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Cummins |
| Model | C1600N6CD |
| Series | HSK78G Genset |
| Configuration | V12 Lean-Burn Turbocharged Aftercooled |
| Cylinders | 12 |
| Displacement | 78 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the Cummins C1600N6CD?
The Cummins C1600N6CD is rated at 2,000 kVA prime at 60 Hz (1,800 rpm).
Does the C1600N6CD run at 50 Hz or 60 Hz?
The Cummins C1600N6CD is rated for 60 Hz (1,800 rpm).
What fuel does the Cummins C1600N6CD use?
The Cummins C1600N6CD is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the C1600N6CD?
The Cummins C1600N6CD is a V12 (12-cylinder) engine with a displacement of 78 L.
Is the Cummins C1600N6CD still in production?
Yes — the Cummins C1600N6CD is a current production model.
Is a datasheet available for the C1600N6CD?
Yes — an official Cummins datasheet for the Cummins C1600N6CD can be downloaded from this page.
