Cummins
Cummins K19N-G4
K19N
Cummins K19N-G4 (CCEC / Chongqing Cummins) — 18.9 L L6 lean-burn spark-ignited gas generator engine. 450 kW continuous engine output, 400 kWe recommended genset power at 1500 rpm (50 Hz) / 1800 rpm (60 Hz). Also offered for biogas (CH₄ ≥ 45%) and associated petroleum gas.
- Prime Power · 50 Hz
- 500 kVA
- Electrical Output
- 400 kWe
- Cylinders
- L6
- Displacement
- 18.9 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 450 | 400 | 500 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 450 | 400 | 500 |
Technical Specifications
| Brand | Cummins |
| Model | K19N-G4 |
| Series | K19N |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 18.9 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
