Cummins
Cummins K38N-G6
K38N
Cummins K38N-G6 (CCEC / Chongqing Cummins) — 37.8 L V12 lean-burn spark-ignited gas generator engine. 680 kW continuous engine output, 600 kWe recommended genset power at 1500 rpm (50 Hz) / 1800 rpm (60 Hz). Also offered for biogas (CH₄ ≥ 45%) and associated petroleum gas.
- Prime Power · 50 Hz
- 750 kVA
- Electrical Output
- 600 kWe
- Cylinders
- V12
- Displacement
- 37.8 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 680 | 600 | 750 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 680 | 600 | 750 |
Technical Specifications
| Brand | Cummins |
| Model | K38N-G6 |
| Series | K38N |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 37.8 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
