Cummins K50N-G11H
K50N
Cummins K50N-G11H (CCEC / Chongqing Cummins) — 50.3 L V16 lean-burn spark-ignited gas generator engine. 1200 kW continuous engine output, 1100 kWe recommended genset power at 1500 rpm (50 Hz) / 1800 rpm (60 Hz). Also offered for biogas (CH₄ ≥ 45%) and associated petroleum gas.
- Prime Power · 50 Hz
- 1,375 kVA
- Electrical Output
- 1,100 kWe
- Cylinders
- V16
- Displacement
- 50.3 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1200 | 1100 | 1375 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1200 | 1100 | 1375 |
Technical Specifications
| Brand | Cummins |
| Model | K50N-G11H |
| Series | K50N |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 50.3 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
