Cummins
Cummins KTA19-G9A
K19 Series
The Cummins KTA19-G9A is a 19-litre inline-6 diesel engine for generator sets, rated at 750 kVA / 600 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Overhaul & repair parts- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 750 kVA
- Electrical Output
- 600 kWe
- Cylinders
- L6
- Displacement
- 19 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 605.6 | 545 | 681.3 |
| Standby Power | 666.7 | 600 | 750 |
Ask about Cummins KTA19-G9A
Choose parts / service or sourcing. Your message includes this model and page link.
Cummins KTA19-G9A overhaul & repair parts
Already running a Cummins KTA19-G9A? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with KTA19-G9A and your selected categories included. Attach your photos there.
Cummins KTA19-G9A generator set context
The Cummins KTA19-G9A is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 750 kVA / 600 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Cummins |
| Model | KTA19-G9A |
| Series | K19 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 19 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Cummins KTA19-G9A?
The Cummins KTA19-G9A is rated at 750 kVA standby / 681 kVA prime at 50 Hz (1,500 rpm).
Does the KTA19-G9A run at 50 Hz or 60 Hz?
The Cummins KTA19-G9A is rated for 50 Hz (1,500 rpm).
What fuel does the Cummins KTA19-G9A use?
The Cummins KTA19-G9A is a diesel generator-set engine.
What is the displacement and cylinder configuration of the KTA19-G9A?
The Cummins KTA19-G9A is an inline-6 (6-cylinder) engine with a displacement of 19 L.
What is the catalog status of the Cummins KTA19-G9A?
The Cummins KTA19-G9A is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the KTA19-G9A?
This page links reference documents for the Cummins KTA19-G9A. Check each document's title, model coverage, revision and rating conditions before using it for selection.
