Cummins KTA50-G12

The Cummins KTA50-G12 is a 50.3-litre V16 diesel engine for generator sets, rated at 1,375 kVA / 1,100 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.

Production StatusIn Production

K50 Series

Representative Cummins engine
Electrical output 50 Hz · 1500 RPM
Prime power1,020 kWe
Standby power1,100 kWe
Configuration
V16
Displacement
50.3 L
Fuel
Diesel

Power Ratings

kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf

50 Hz1500 RPM

RatingPrimeStandby
Mechanical power kWm1,133.31,222.2
Electrical output kWe1,0201,100
Apparent power kVA1,2751,375

60 Hz1800 RPM

RatingPrimeStandby
Mechanical power kWm1,255.61,311.1
Electrical output kWe1,1301,180
Apparent power kVA1,412.51,475

Datasheet & documents

Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.

View KTA50-G12 spec image
Shareable spec cardCummins KTA50-G12 summary imageOpen image
Cummins KTA50-G12 50.3L V16 diesel generator engine — 1,375 kVA standby specifications

Technical specifications

Technical Specifications

BrandCummins
ModelKTA50-G12
SeriesK50 Series
ConfigurationV16
Cylinders16
Displacement50.3 L
Fuel TypeDiesel
Ignition TypeCompression Ignition
Cooling MethodLiquid-Cooled
Emissions StandardUnregulated
Country of OriginChina

Check your engine model

The Cummins KTA50-G12 is a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 1,375 kVA / 1,100 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.

Other ways this model is written

kta50g12KTA50 G12Cummins KTA50-G12K50 Series KTA50-G12

KTA50-G12 repair parts

Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.

Get a parts & air-shipping quote
In-stock parts: same-day dispatch

Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.

Find the right part

Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.

Which parts do you need?

Other parts? Add them in the chat.

Get my parts quote on WhatsApp

We’ll confirm the correct parts, stock and delivery cost before you order.

Opens WhatsApp. Attach photos in the chat.

Photos and details to send
  1. Take a clear photo of the engine nameplate.
  2. Tell us what needs repair or replacement.
  3. Send both in WhatsApp to start a fitment check.
How to read your engine nameplate

These categories have model-related records. Part numbers need further checking before we display them here.

Get help with this engine

Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.

Opens WhatsApp. You can edit your message before sending.

Other ways to contact us
Scan QRHide QRHaifeng general WhatsApp chat QR codeGeneral WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales team

Need help after checking the documents?

Send us the part number or describe the problem. This engine model is included in your message.

Send this model enquiry by email

Or browse Haifeng's diesel generator sets

Frequently asked questions

What is the power output of the Cummins KTA50-G12?

The Cummins KTA50-G12 is rated at 1,375 kVA standby / 1,275 kVA prime at 50 Hz (1,500 rpm); and 1,475 kVA standby / 1,413 kVA prime at 60 Hz (1,800 rpm).

Does the KTA50-G12 run at 50 Hz or 60 Hz?

The Cummins KTA50-G12 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).

What fuel does the Cummins KTA50-G12 use?

The Cummins KTA50-G12 is a diesel generator-set engine.

What is the displacement and cylinder configuration of the KTA50-G12?

The Cummins KTA50-G12 is a V16 (16-cylinder) engine with a displacement of 50.3 L.

What is the catalog status of the Cummins KTA50-G12?

The Cummins KTA50-G12 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.

Are reference documents available for the KTA50-G12?

This page links reference documents for the Cummins KTA50-G12. Check each document's title, model coverage, revision and rating conditions before using it for selection.
