Cummins
Cummins KTAA19-G6A
K19 Series
The Cummins KTAA19-G6A is a 19-litre inline-6 diesel engine for generator sets, rated at 688 kVA / 550 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Overhaul & repair parts- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 688 kVA
- Electrical Output
- 550 kWe
- Cylinders
- L6
- Displacement
- 19 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 611.1 | 550 | 687.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 666.7 | 600 | 750 |
Ask about Cummins KTAA19-G6A
Choose parts / service or sourcing. Your message includes this model and page link.
Cummins KTAA19-G6A overhaul & repair parts
Already running a Cummins KTAA19-G6A? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with KTAA19-G6A and your selected categories included. Attach your photos there.
Cummins KTAA19-G6A generator set context
The Cummins KTAA19-G6A is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 688 kVA / 550 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Cummins |
| Model | KTAA19-G6A |
| Series | K19 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 19 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Cummins KTAA19-G6A?
The Cummins KTAA19-G6A is rated at 688 kVA standby at 50 Hz (1,500 rpm); and 750 kVA standby at 60 Hz (1,800 rpm).
Does the KTAA19-G6A run at 50 Hz or 60 Hz?
The Cummins KTAA19-G6A is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Cummins KTAA19-G6A use?
The Cummins KTAA19-G6A is a diesel generator-set engine.
What is the displacement and cylinder configuration of the KTAA19-G6A?
The Cummins KTAA19-G6A is an inline-6 (6-cylinder) engine with a displacement of 19 L.
What is the catalog status of the Cummins KTAA19-G6A?
The Cummins KTAA19-G6A is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the KTAA19-G6A?
This page links reference documents for the Cummins KTAA19-G6A. Check each document's title, model coverage, revision and rating conditions before using it for selection.
