Cummins
Cummins QSK19-G4
QSK19 Series
The Cummins QSK19-G4 is a 19-litre inline-6 diesel engine for generator sets, rated at 713 kVA / 570 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Overhaul & repair parts- Supporting documents
- 1 document · 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 713 kVA
- Electrical Output
- 570 kWe
- Cylinders
- L6
- Displacement
- 19 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 577.8 | 520 | 650 |
| Standby Power | 633.3 | 570 | 712.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 555.6 | 500 | 625 |
| Standby Power | 633.3 | 570 | 712.5 |
Ask about Cummins QSK19-G4
Choose parts / service or sourcing. Your message includes this model and page link.
Cummins QSK19-G4 overhaul & repair parts
Already running a Cummins QSK19-G4? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with QSK19-G4 and your selected categories included. Attach your photos there.
Cummins QSK19-G4 generator set context
The Cummins QSK19-G4 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 713 kVA / 570 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Cummins |
| Model | QSK19-G4 |
| Series | QSK19 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 19 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Cummins QSK19-G4?
The Cummins QSK19-G4 is rated at 713 kVA standby / 650 kVA prime at 50 Hz (1,500 rpm); and 713 kVA standby / 625 kVA prime at 60 Hz (1,800 rpm).
Does the QSK19-G4 run at 50 Hz or 60 Hz?
The Cummins QSK19-G4 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Cummins QSK19-G4 use?
The Cummins QSK19-G4 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the QSK19-G4?
The Cummins QSK19-G4 is an inline-6 (6-cylinder) engine with a displacement of 19 L.
What is the catalog status of the Cummins QSK19-G4?
The Cummins QSK19-G4 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the QSK19-G4?
This page links reference documents for the Cummins QSK19-G4. Check each document's title, model coverage, revision and rating conditions before using it for selection.
