Cummins
Cummins QSK38-G5A
QSK38 Series
The Cummins QSK38-G5A is a 37.7-litre V12 diesel engine for generator sets, rated at 1,501 kVA / 1,201 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Get help with this engine
Tell Haifeng whether you already own a Cummins QSK38-G5A engine/generator or need to source this model for a project.
- Manufacturer files
- 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,501 kVA
- Electrical Output
- 1,201 kWe
- Cylinders
- V12
- Displacement
- 37.7 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1212.2 | 1091 | 1363.8 |
| Standby Power | 1334.4 | 1201 | 1501.3 |
Cummins QSK38-G5A generator set context
The Cummins QSK38-G5A is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 1,501 kVA / 1,201 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Cummins |
| Model | QSK38-G5A |
| Series | QSK38 Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 37.7 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Cummins QSK38-G5A?
The Cummins QSK38-G5A is rated at 1,501 kVA standby / 1,364 kVA prime at 50 Hz (1,500 rpm).
Does the QSK38-G5A run at 50 Hz or 60 Hz?
The Cummins QSK38-G5A is rated for 50 Hz (1,500 rpm).
What fuel does the Cummins QSK38-G5A use?
The Cummins QSK38-G5A is a diesel generator-set engine.
What is the displacement and cylinder configuration of the QSK38-G5A?
The Cummins QSK38-G5A is a V12 (12-cylinder) engine with a displacement of 37.7 L.
Is the Cummins QSK38-G5A still in production?
Yes — the Cummins QSK38-G5A is a current production model.
Is a datasheet available for the QSK38-G5A?
Yes — an official Cummins datasheet for the Cummins QSK38-G5A can be downloaded from this page.
