Cummins
Cummins QSK50-G4
QSK50 Series
The Cummins QSK50-G4 is a 50.3-litre V16 diesel engine for generator sets, rated at 1,700 kVA / 1,360 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in United States. It meets U.S. EPA Tier 2 emissions standards.
Get help with this engine
Tell Haifeng whether you already own a Cummins QSK50-G4 engine/generator or need to source this model for a project.
- Manufacturer files
- 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,700 kVA
- Electrical Output
- 1,360 kWe
- Cylinders
- V16
- Displacement
- 50.3 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1368.9 | 1232 | 1540 |
| Standby Power | 1511.1 | 1360 | 1700 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1516.7 | 1365 | 1706.3 |
| Standby Power | 1666.7 | 1500 | 1875 |
Cummins QSK50-G4 generator set context
The Cummins QSK50-G4 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,700 kVA / 1,360 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Cummins |
| Model | QSK50-G4 |
| Series | QSK50 Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 50.3 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the Cummins QSK50-G4?
The Cummins QSK50-G4 is rated at 1,700 kVA standby / 1,540 kVA prime at 50 Hz (1,500 rpm); and 1,875 kVA standby / 1,706 kVA prime at 60 Hz (1,800 rpm).
Does the QSK50-G4 run at 50 Hz or 60 Hz?
The Cummins QSK50-G4 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Cummins QSK50-G4 use?
The Cummins QSK50-G4 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the QSK50-G4?
The Cummins QSK50-G4 is a V16 (16-cylinder) engine with a displacement of 50.3 L.
What emissions standard does the QSK50-G4 meet?
The Cummins QSK50-G4 is certified to U.S. EPA Tier 2 emissions standards.
Is the Cummins QSK50-G4 still in production?
Yes — the Cummins QSK50-G4 is a current production model.
Is a datasheet available for the QSK50-G4?
Yes — an official Cummins datasheet for the Cummins QSK50-G4 can be downloaded from this page.
