FAWDE
FAWDE CA6DF2
CA6D Series
FAWDE (FAW Wuxi) CA6DF2 6L 6-cylinder diesel engine for generator sets. 106 kWe standby at 50Hz. Turbocharged Intercooled.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-11
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 133 kVA
- Electrical Output
- 106 kWe
- Cylinders
- L6
- Displacement
- 6 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 106.7 | 96 | 120 |
| Standby Power | 117.8 | 106 | 132.5 |
Ask about FAWDE CA6DF2
Choose parts / service or sourcing. Your message includes this model and page link.
FAWDE CA6DF2 overhaul & repair parts
Already running a FAWDE CA6DF2? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with CA6DF2 and your selected categories included. Attach your photos there.
FAWDE CA6DF2 generator set context
The FAWDE CA6DF2 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 133 kVA / 106 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | FAWDE |
| Model | CA6DF2 |
| Series | CA6D Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 6 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the FAWDE CA6DF2?
The FAWDE CA6DF2 is rated at 133 kVA standby / 120 kVA prime at 50 Hz (1,500 rpm).
Does the CA6DF2 run at 50 Hz or 60 Hz?
The FAWDE CA6DF2 is rated for 50 Hz (1,500 rpm).
What fuel does the FAWDE CA6DF2 use?
The FAWDE CA6DF2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the CA6DF2?
The FAWDE CA6DF2 is an inline-6 (6-cylinder) engine with a displacement of 6 L.
What is the catalog status of the FAWDE CA6DF2?
The FAWDE CA6DF2 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the CA6DF2?
This page links reference documents for the FAWDE CA6DF2. Check each document's title, model coverage, revision and rating conditions before using it for selection.
