Ford
Ford MSG425
MSG
Ford Power Products MSG425 — 2.5 L L4 spark-ignition genset engine, naturally aspirated, bi-fuel natural gas / LPG. 34.7 kWm (46.6 hp) on natural gas, 36 kWm (48.7 hp) on LPG at 1800 rpm (SAE J1349 intermittent); 9.7:1 compression, EPA/CARB certified with 3-way catalyst.
- Prime Power · 60 Hz
- 39 kVA
- Electrical Output
- 31 kWe
- Cylinders
- L4
- Displacement
- 2.5 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 34.7 | 31 | 38.8 |
Technical Specifications
| Brand | Ford |
| Model | MSG425 |
| Series | MSG |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 2.5 L |
| Compression Ratio | 9.7 |
| Dry Weight | 159.2 kg |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | EPA Certified |
| Certifications | EPA, CARB, 3-way catalyst |
| Country of Origin | United States |
